SNAP SWITCHES
DK sub-sub-
miniature switch
Technical speci?cations
Features
Contact con?guration
Contact gap
Switching voltage max.
Switched current
Operating force max.
Total travel
Mechanical life
Electrical life (max. load)
Ambient temperature
Materials
Base
Cover
Actuator
Auxiliary actuator
Sealing gasket
Terminals
Leads
Contacts
Degree of protection
S.P.D.T.
< 3 mm
12 V DC
up to 60 V on request
0,005 bis 2 A DC
75 cN
without auxiliary actuator
ca. 2,0 mm
min. 500.000 operations
min. 100.000 operations
– 40 to +85 °C / 105°C
PBT / PES
PBT + ASA
POM (+85°)
Stainless steel
SI (VMQ)
CuZn (silver-plated)
Cu, Isolation PVC
AuAg (Crosspoint)
IP65, IP67 on request
? Sealed switch up to protection IP65. IP67 on request
? Smallest dimensions
? Models available up to 105 °C operating temperature
? Nominal currents 5 mA up to 2 A at 12 V DC
? Actuation vertically or with auxiliary actuator
? High contact stability thanks to AuAg crosspoint contacts
? Mechanical operating life min. 500.000 actuations
? Many connection possibilities, also available with leads
(switch interior)
For detailed information and the layout of the details described above,
please do not hesitate to ask for our technical speci?cations and drawing.
